JIB Crane
Flexible Localized Lifting | Space-Saving Design | Precision Handling
Globe MachMovers is a leading JIB Crane manufacturer in India, offering a wide range of floor-mounted, wall-mounted, and pillar-mounted jib cranes designed for localized material handling. Our jib cranes are perfect for workstation-level lifting tasks, offering 360° rotation, ease of operation, and cost-effective performance in small to mid-scale industrial environments.
What is a JIB Crane?
A JIB Crane is a fixed or wall-mounted lifting system with a horizontal jib arm, supporting a hoist or lifting mechanism that travels along the arm. The crane can rotate between 180° to 360°, depending on the design, allowing for quick, accurate, and controlled lifting and positioning of loads. Available in manual and motorized rotation options, it is suitable for both indoor and outdoor use.
Technical Specifications
| Crane Type | Jib Crane (Wall Mounted / Floor Mounted / Pillar Mounted / Wall Travelling) |
|---|
| Capacity Range | 0.25 Ton to 5 Ton (customizable up to 10 Ton) |
|---|
| Boom Length (Arm Span) | Up to 6 meters (customizable) |
|---|
| Slewing Range | 180° / 270° / 360° (manual or motorized slewing) |
|---|
| Lifting Height | Up to 6 meters (as per site requirement) |
|---|
| Hoist Type | Manual Chain Hoist / Electric Chain Hoist / Wire Rope Hoist |
|---|
| Mounting Type | Floor Mounted (Pillar), Wall Mounted, or Wall Travelling |
|---|
| Column Construction | Heavy-Duty MS Pipe / Fabricated Steel Section (IS Standard) |
|---|
| Boom Type | I-Beam / Box Beam with Trolley Arrangement |
|---|
| Slewing Mechanism | Manual Push Pull / Electric Motorized with Gearbox |
|---|
| Rotation Limit | Mechanical / Electrical Stopper (optional) |
|---|
| Power Supply | 3 Phase, 415V AC, 50Hz (for electric hoist and rotation motor) |
|---|
| Control Type | Push Button Pendant / Remote Control (optional) |
|---|
| Finish | Industrial Grade Paint / Epoxy / Powder Coated |
|---|
| Design Standards | IS 807 / IS 3938 / IS 3177 / ANSI / OSHA |
|---|
| Installation | Anchored with Foundation Bolts / Mounted on Existing RCC Structure (for wall type) |
|---|
| Safety Features | Overload Protection, Emergency Stop, Limit Switches, Rotation Stopper |
|---|
| Applications | Machine Shops, Assembly Lines, Docks, Warehouses, Loading Bays |
|---|
Key Features
- Load Capacity: 250 kg to 5,000 kg (customizable)
- Rotation Range: 180° to 360° (manual or electric)
- Mounting Options: Floor-mounted, wall-mounted, pillar-mounted
- Jib Arm: I-beam or box beam for durability and hoist compatibility
- Lifting Mechanism: Manual chain hoist or electric wire rope hoist
- Construction: Heavy-duty mild steel (MS) with powder coating or galvanized finish
- Safety Features: Overload protection, limit switches, anti-rollback systems
- Customization: Arm length, height under boom, rotation, and mounting type
Applications
- Precision lifting and load handling at workstations
- Machine loading/unloading in workshops
- Material handling in assembly lines and repair bays
- Mold and tool lifting in tool rooms
- Small parts handling at fabrication units
- Dockside operations and shipping yards
Industries We Serve
- Engineering & Fabrication
- Automotive & Aerospace
- Warehousing & Packaging
- Marine & Shipyards
- Maintenance & Utilities
- Power Plants & Industrial Workshops
Benefits of Globe MachMovers’ JIB Cranes
Our JIB Cranes offer a localized lifting solution designed for dedicated work zones, a space-saving design with no need for overhead structures or rails, 360° flexibility for a wide coverage area, high precision with smooth and controlled movement of loads, and low maintenance with a simple structure that is easy to operate and service.
Why Choose JIB Cranes from Globe MachMovers?
- Reputed JIB Crane manufacturer in India with custom-built solutions
- Designed and fabricated to IS/ISO standards
- Superior materials, precision welding, and top-grade components
- Available in both light-duty and heavy-duty variants
- Nationwide delivery, installation, and service support
Need a smart lifting solution for localized work areas?
Contact Globe MachMovers, your trusted JIB Crane supplier in India, and empower your facility with flexible and efficient lifting systems tailored to your needs.
Enhance your operations with our reliable and versatile jib cranes.
