High Rise Scissor Lift
Safe | Stable | High-Lifting | Designed for Elevated Access & Maintenance
At Globe Mach Movers, we manufacture and supply advanced High-Rise Scissor Lifts engineered for safe elevated access, high stability, and heavy-duty industrial operations. Our lifts are designed for construction, facility maintenance, airports, factories, warehouses, malls, and infrastructure projects requiring reliable vertical access up to 18–20 meters.
Built with reinforced scissor arms, high-tensile steel structure, hydraulic/electric drive systems, and global-standard safety features, these lifts ensure safe working conditions for operators and equipment at multiple levels.
Product Overview
Our High-Rise Hydraulic Scissor Lifts integrate:
- Heavy-duty hydraulic cylinders with hose burst protection
- Customizable platforms with fixed/extendable options
- Mobility solutions (towable, battery-driven, or self-propelled)
- Low-noise power packs for indoor and outdoor use
These lifts are the ideal solution where ladders and scaffolding fall short, offering stable lifting, increased safety, and operational efficiency.
Technical Specifications
| Parameter | Specification (Global Standard Reference) |
|---|
| Lift Type | High-Rise Hydraulic / Electro-Hydraulic Scissor Lift (Mobile or Fixed) |
|---|
| Rated Load Capacity | 300 kg – 2000 kg (standard), customizable up to 5000 kg for material handling |
|---|
| Maximum Platform Height | 6 m – 18 m (extendable to 20 m) |
|---|
| Working Height | Up to 20–22 m (including operator reach) |
|---|
| Minimum Collapsed Height | 100 mm – 250 mm (model dependent) |
|---|
| Platform Dimensions | 2.5 m × 1.2 m (standard); extendable up to 3.0 m × 2.5 m with roll-out deck |
|---|
| Platform Extension | Up to 1.2 m roll-out deck (optional) |
|---|
| Lifting/Lowering Speed | 20 – 60 seconds (depending on model) |
|---|
| Drive Type | Towable (manual), Battery-operated (DC), Diesel-powered, or Self-Propelled AC/DC |
|---|
| Power Supply Options | 220V Single Phase, 380V–415V Three Phase, 24V/48V DC Battery Pack, or Diesel Engine |
|---|
| Motor Power | 2.2 kW – 7.5 kW (hydraulic or traction) |
|---|
| Control System | Proportional Joystick (self-propelled models) / Push Button Control (stationary models) |
|---|
| Hydraulic System | Dual/Quad Cylinder with Flow Control & Hose Burst Safety Valves |
|---|
| Safety Systems | Emergency Stop, Overload Sensor, Guardrails & Toe Boards, Tilt Sensor, Descent Alarm, Manual Lowering, Anti-sway Design |
|---|
| Surface Finish | Powder Coated (70–90 μm) or Hot Dip Galvanized (for outdoor models) |
|---|
| Tyres / Mobility Options | PU/Nylon wheels, Pneumatic tyres, Non-marking tyres, Tow-bar hitch, or Self-propelled drive |
|---|
| Stabilizers/Outriggers | Automatic / Manual Outriggers with Safety Interlock |
|---|
| Noise Level | ≤ 70 dB (low-noise hydraulic pump) |
|---|
| Ingress Protection | IP54 Control Panels (IP65 optional) |
|---|
| Operating Temperature | -10°C to +55°C (cold climate package available) |
|---|
| Standards Compliance | EN 280, ISO 16368, ANSI A92, CE Machinery Directive, IS 8140 |
|---|
Key Features
- Working Height: Up to 20–22 m (operator reach)
- Load Capacity: 300 kg – 2000 kg, with heavy-duty models up to 5000 kg
- Drive Options: Towable, self-propelled (electric/diesel), or stationary hydraulic
- Safety Enhancements: Emergency stop, tilt sensor, overload cut-off, hose burst protection, interlocked outriggers
- Platform Options: Fixed, extendable deck, foldable guardrails
- Mobility Choices: Manual push, battery-powered, diesel-driven, or hybrid dual-power
- Energy Efficient: AC/DC models with regenerative braking (on self-propelled versions)
- User Comfort: Low-noise operation, smooth start-stop hydraulics, anti-sway scissor design
Applications
- Electrical & Mechanical Installation
- Building Facade & Glass Cleaning
- Warehouse & Factory Maintenance
- HVAC & Lighting Installation
- Airports & Railway Terminal Servicing
- Shopping Mall & Exhibition Hall Maintenance
- High-rise Window & Roof Access
Industries We Serve
- Construction & Infrastructure
- Manufacturing & Warehousing
- Facility Management & Maintenance
- Airports & Railways
- Shopping Malls & Exhibition Centers
- Government Buildings & Utilities
Benefits of Globe MachMovers’ High Rise Scissor Lifts
- Safe Elevated Access – Certified to EN 280 / ANSI A92
- Stable Operation – Wide base, cross-braced scissors, and outriggers
- Custom-Built – Platform size, lift range, and power options tailored to site needs
- Indoor & Outdoor Ready – Non-marking tyres, corrosion-proof coating, weather-resistant design
- Easy Maintenance – Simple hydraulic system with accessible service points
- Durable & Long-lasting – Designed for 24/7 industrial-grade use
Why Choose Globe MachMovers?
- ISO & CE Certified High-Rise Scissor Lift Manufacturer
- Wide model range for 6 m – 20 m vertical access
- Fully customizable to site-specific requirements
- End-to-end solutions – from consultation to commissioning
- Trusted by global contractors, facility managers, and OEMs
Get Your Quote Today!
Looking to enhance your workplace height safety and vertical access?
Contact Globe Machmovers today for a customized high-rise scissor lift solution engineered for maximum safety, stability, and performance.
